AU5901,AU5901A  luminaire is made of 3 mail parts:

THE TOP COVER in octagonal diecast aluminium held to the Ring body.

RING BODY  in aluminium dicast. The frame is attached by means of an hinge and 3 S/S screw,under the body,assureing and easy access to the control gear and lamp.

THE OPTIC SYSTEM It comprises a pure refined aluminium reflector,stamped out in one piece and polished which is attaqched to the frame,and another CDG steel reflector fixed with aluminium reflector,A arc tempered glass is sealed directly to the CDG steel reflector by means of a silicone seal insuring a high degree of protection.

Post luminaire or hanging luminaire for your choice.

Painted by polyester powder,color on request.

PROTCTION DEGREE:

Optical block IP66

SHOCK ENERGY

20 Joules(tempered glass)

CLASS I

CLASS II on request
